Test box material

1. Test box size: diameter 400mm x depth 500 (mm) circular test box (customizable)

2. Overall dimensions: 900x 850 x 1800 mm (W * D * H) vertical (customizable)

3. Inner bucket material: stainless steel plate material (SUS # 316 3mm)

4. Outer bucket material: stainless steel plate material or precision spray coating

5. Insulation material: Rock wool and hard polyurethane foam insulation

6. Steam generator heating tube: titanium tube heating, never rusting.

Control System

1) Using Taiwan made Delta color touch PLC to control humidity and steam temperature (using PT-100 platinum temperature sensor)

2) Using both pointers and controllers to display pressure accurately and reliably

3) Microcomputer P.I.D automatic calculation and control of saturated steam temperature and steam humidity

4) Manual water inlet valve (automatic water replenishment function, can be tested continuously without stopping the machine)

5) Export experimental data from USB drive and query curves.

prevent local damage to the product.

3) The electric labor-saving structure of the door lock is safe and reliable.

4) Test front cold air; The design of discharging cold air during the experiment (discharging air from the test bucket) improves pressure stability and reproducibility

5) Ultra long experimental operation time

6) Water level protection, detected by the water level sensor in the laboratory

7) Tank pressure resistant design, the box body can withstand pressure (150 ℃) of 2.65kg, which meets the water pressure test of 6kg

8) The two-stage pressure safety protection device adopts a combination of two-stage controller and mechanical pressure protection device

9) Safety protection pressure relief button, emergency safety device two-stage automatic pressure relief button

10) The voltage withstand of the bias test terminal can reach 3000V (optional)

11) Export historical data and curves via USB
